TOYOLIFT Beam Clamp 5 Ton ,UK – (76BC5)
The TOYO Beam Clamp offers reliable, heavy-duty lifting for beams, with capacities ranging from 1 to 10 tons. Designed for versatility, it adjusts to flange widths between 75-320 mm, ensuring a secure fit. Built to meet EN 13155 standards, it ensures maximum safety in industrial and construction settings. Durable and easy to install, it’s the perfect solution for lifting and rigging tasks.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
Product Description
The TOYOLIFT Beam Clamp is a versatile and heavy-duty lifting solution designed for securely attaching to beams for lifting and positioning applications. This high-strength clamp is ideal for construction, industrial, and rigging environments, where safe load handling is crucial.
Available in five different models (TL-BC010, TL-BC020, TL-BC030, TL-BC050, TL-BC100), this clamp offers rated load capacities ranging from 1 ton to 10 tons, with tested loads reaching up to 1.5 times the rated capacity. The flange width adaptability spans from 75 mm to 320 mm, ensuring compatibility with a wide range of beams. Additionally, the clamp is engineered to meet the stringent EN 13155 standard, ensuring optimal safety and reliability.
Key specifications include:
- Model TL-BC010: Rated load 1 ton, tested load 1.5 tons, flange width 75-220 mm, net weight 4.5 kg.
- Model TL-BC020: Rated load 2 tons, tested load 3 tons, flange width 75-220 mm, net weight 5 kg.
- Model TL-BC030: Rated load 3 tons, tested load 4.5 tons, flange width 80-320 mm, net weight 10.5 kg.
- Model TL-BC050: Rated load 5 tons, tested load 7.5 tons, flange width 80-320 mm, net weight 11 kg.
- Model TL-BC100: Rated load 10 tons, tested load 15 tons, flange width 90-320 mm, net weight 16 kg.
The clamp’s robust design features maximum durability, with adjustable widths, reinforced joints, and easy installation, making it suitable for a wide range of lifting applications. Whether you’re securing materials for transport or need a reliable solution for beam handling, the TOYO Beam Clamp is engineered to provide safety and efficiency in every lift.
Parameters
| Model | Rated Load (Ton) | Tested Load (Ton) | Flange width (mm) | Max. A (mm) | Min. B (mm) | Max. B (mm) | C (mm) | D (mm) | E (mm) | Max. F (mm) | Min. F (mm) | Min. G (mm) | H (mm) | Net weight (Kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TL-BC010 | 1 | 1.5 | 75-220 | 260 | 180 | 260 | 64 | 5 | 215 | 155 | 102 | 25 | 22 | 4.5 |
| TL-BC020 | 2 | 3 | 75-220 | 260 | 180 | 360 | 74 | 6 | 215 | 155 | 102 | 25 | 22 | 5 |
| TL-BC030 | 3 | 4.5 | 80-320 | 354 | 235 | 490 | 103 | 8 | 260 | 225 | 140 | 45 | 24 | 10.5 |
| TL-BC050 | 5 | 7.5 | 80-320 | 354 | 235 | 490 | 110 | 10 | 260 | 225 | 140 | 45 | 28 | 11 |
| TL-BC100 | 10 | 15 | 90-320 | 365 | 320 | 505 | 120 | 12 | 280 | 225 | 140 | 50 | 40 | 16 |
Standards and Certifications
- EN 13155.
Detailed Specifications
| Usually ships in | 4 weeks |
|---|---|
| Manufacturer | TOYOLIFT U.K LTD |
| Brand | TOYOLIFT |
| Price Unit | Each |
| Weight | 1.300 KG |
| Is Featured | No |
