TOYOLIFT Electric Chain Hoist, 3 Ton, 6 Meter – 76ECB-SSDHL-LS

Product Description

The TOYOLIFT SSDHL electric chain hoist (Model SSDHL01-01S) is designed for industrial-grade lifting and precision control. It operates with a 1.5 kW motor on a 3-phase 415V, 50/60Hz power supply and delivers a lifting speed of 6.6 m/min. Equipped with a single-fall chain, chain bag, and remote control, it also features a built-in load cell and load limit indicator for enhanced safety. Up and down limit switches are included, and the hoist is protected with an IP54-rated enclosure. Built for demanding use, it meets the M5 / 2m duty classification under ISO/FEM standards.

Features

• Load Capacity: Ranges from 0.5 Ton to 50 Ton

• Control Method: Operated using a durable push-button pendant

• Lifting Options: Supports both single-speed and dual-speed modes

• Power Supply: Compatible with 3-phase, 380V or 415V, 50/60Hz systems

• Control Voltage: Available in 24V or 36V for operator safety

• Duty Rating: M5 working group—ideal for intensive use

• Motor Insulation: Class F insulation for thermal protection and long service life

• Protection Level: IP54-rated hoist body; push button rated IP65; full hoist and trolley protection up to IP65 available upon request

• Power Feed: Suspension-type cable feeding; works with manual, chain-driven, or motorized trolleys; includes 6m cable or optional wireless remote (note: cable and catch not included in standard package)

• Push Button Configuration: 2-button for single speed; 4-button for dual speed operation

• Start Frequency: Handles up to 150 operations per hour

• Mounting Options: Can be mounted via hook, manual trolley, or electric trolley

• Operating Temperature Range: -20°C to 45°C (−4°F to 113°F)

• Humidity Tolerance: Functions reliably in environments with up to 85% relative humidity

User Guide

• This hoist is intended exclusively for vertical lifting at a 90-degree angle—do not use it for angled or horizontal pulling.

• The equipment must be operated only by trained personnel who have read the user manual and completed a proper pre-use inspection.

• To prevent motor overheating, allow cooling periods during every hour of operation, especially in high ambient temperatures.

• Always keep the load chain clean, well-lubricated, and rust-free. Ensure it’s correctly stored in the chain container with the limit spring and chain stopper properly installed.

Specifications

Standards & Compliance

• EN ISO 12100:2010 – Establishes general design principles focused on risk assessment and reduction for machinery safety.

• EN 14492-2:2006 + A1:2009 – Specifies safety requirements for power-operated hoists used in lifting applications.

• EN 818-7:2002 + A1:2008 – Covers safety specifications for short link chains used in lifting, specifically fine tolerance hoist chains of Grade T (Types T, DAT, and DT).

• EN 349:1993 + A1:2008 – Defines the minimum safety clearances to prevent crushing injuries from moving parts on machinery.
