TOYOLIFT Electric Chain Hoist, 5 Ton, 6 Meter – 76ECB-SSDHL-LS
The TOYOLIFT SSDHL 5 Ton Electric Chain Hoist is built for demanding industrial lifting with precision and safety in mind. Featuring a 6-meter lift height and a powerful motor, it delivers smooth, controlled operation at 6.6 m/min. Equipped with a remote, load limiter, and IP-rated protection, it’s ready for tough environments. Ideal for factories, construction, and heavy-duty applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
Product Description
The TOYOLIFT SSDHL electric chain hoist (Model SSDHL01-01S) is engineered for tough lifting applications, featuring a powerful 1.5 kW motor operating on 3-phase 415V, 50/60Hz. It delivers a smooth lifting speed of 6.6 m/min and includes a single-fall chain with a heavy-duty chain bag. For added safety and precision, the hoist is equipped with a remote control, load cell, and load limit indicator. It also features upper and lower limit switches and an IP54-rated enclosure for enhanced protection. Designed for demanding industrial use, it complies with M5/2m (ISO/FEM) duty cycle standards.
Features
-
Load Capacity: Supports lifting capacities ranging from 0.5 Ton to 50 Ton
-
Control System: Operated via a user-friendly push-button pendant
-
Lifting Modes: Available in both single-speed and dual-speed configurations
-
Power Supply: Runs on 3-phase 380V or 415V, 50/60Hz
-
Control Voltage: Available in 24V or 36V for enhanced operator safety
-
Duty Classification: M5 working group for continuous, heavy-duty use
-
Motor Insulation: Equipped with Class F insulation for high thermal resistance
-
Ingress Protection: Hoist body rated IP54, push button IP65; optional IP55/IP65 available for full hoist and trolley
-
Power Feed System: Suspension-type cable feeding, compatible with manual or chain-driven trolleys, 6m cable or optional wireless remote (cable and catch not included in standard package)
-
Push Button Configuration: 2-button for single-speed, 4-button for dual-speed operation
-
Operational Frequency: Supports up to 150 starts per hour
-
Mounting Options: Suitable for hook suspension, manual trolley, or electric trolley setups
-
Temperature Range: Operates reliably from -20°C to 45°C (-4°F to 113°F)
-
Humidity Resistance: Handles up to 85% relative humidity for versatile usage conditions
User Guide
-
This hoist is strictly intended for vertical lifting at a 90-degree angle. Do not use for angled or side pulling operations.
-
Only trained and qualified operators should use this equipment, and they must first read the user manual and complete a full inspection.
-
To prevent overheating, allow adequate cooling time within every hour of use, especially in higher ambient temperatures.
-
The load chain must be clean, properly lubricated, and rust-free, and should be stored in the chain container with the limit spring and chain stopper correctly installed.
Specifications
| Capacity (Ton) | Lifting Speed (m/min) | Motor Power (kW) | Dia of Chain (mm) | No. of Chain Falls | Weight (kg) |
|---|---|---|---|---|---|
| 0.5 | 7.2 | 0.8 | 6.3 | 1 | 52 |
| 1 | 6.6 | 1.5 | 7.1 | 1 | 72 |
| 2 | 6.6 | 3.0 | 10.0 | 1 | 129 |
| 3 | 4.4 | 3.0 | 11.2 | 2 | 150 |
| 5 | 2.7 | 3.0×2 | 11.2 | 2 | 165 |
| 7.5 | 1.8 | 3.0×2 | 11.2 | 3 | 198 |
| 10 | 2.7 | 3.0×2 | 11.2 | 4 | 369 |
| 15 | 1.8 | 3.0×2 | 11.2 | 6 | 412 |
| 20 | 1.4 | 3.0×2 | 11.2 | 8 | 522 |
| 25 | 1.1 | 3.0×2 | 11.2 | 10 | 540 |
| 30 | 0.9 | 3.0×2 | 11.2 | 12 | 820 |
| 50 | 0.55 | 3.0×2 | 11.2 | 20 | 930 |
Standards and Compliance
-
EN ISO 12100:2010 – Specifies essential design principles, focusing on risk assessment and the reduction of hazards in machinery.
-
EN 14492-2:2006 + A1:2009 – Sets safety requirements for power-driven hoists used in lifting applications.
-
EN 818-7:2002 + A1:2008 – Covers safety specifications for fine tolerance short link chains (Grade T – Types T, DAT, and DT) used in hoisting.
-
EN 349:1993 + A1:2008 – Defines minimum safe clearances to prevent injuries caused by crushing between moving machine parts.
Detailed Specifications
| Usually ships in | 4 weeks |
|---|---|
| Manufacturer | TOYOLIFT U.K LTD |
| Brand | TOYOLIFT |
| Price Unit | Each |
| Weight | 165.000 KG |
