UNI-T Ultrasonic Thickness Gauge
UT345A is an intelligent ultrasonic thickness gauge that adopts the latest high-performance and low-power consumption microprocessor technology. Based on the principle of ultrasonic measurement, it can measure the thickness and sound velocity of metal and other materials. It can detect the thinning of pipes and pressure vessels after corrosion, and can make accurate measurements of plates and machined parts. The gauge can be widely used in petroleum, chemical, metallurgy, shipbuilding, aviation, aerospace, and other fields.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
-
-
Features
- 3.7V 2000mAh lithium battery
- Auto calibration
- 300 groups of data storage
- High-sensitive probe
- Buzzer alarm
- Multiple materials selection
- Main functions: single measurement, continuous measurement, alarm, sound velocity measurement, auto-calibration
Specifications
Display 2.4″ LCD Measurement range 1.00~300.00mm Sound velocity range (1000～9999) m/s Unit mm/in Accuracy H<10mm, ±0.1mm; H≥10mm, ±(1%H+0.1)mm Lower limit of pipe measurement Φ20×3mm (steel) Data storage 300 groups, including material, sound velocity, unit, measured value, MAX, MIN and AVG of each group Main functions Single measurement, continuous measurement, alarm, sound velocity measurement, auto calibration Charging specification DC 5V 1A, Type-C interface Operating time (full battery) About 16h Operating temperature and humidity 0℃~40℃ 10%RH~80%RH Storage temperature and humidity -10℃~50℃ 10%RH~70%RH General Characteristics Battery Built-in lithium battery (3.7V 2000mAh) Product color Red and grey Product net weight 175g Product size 140×66×28.5mm Standard accessories Type-C charging cable, Probe Gross weight (one carton) 3.09kg
-
| Manufacturer | UNI-T |
|---|---|
| Price Unit | Each |
| Weight | 0.175 KG |
| Is Featured | No |
