UNI-T UT505 Series Handheld Insulation Resistance Testers
handheld true RMS insulation resistance testers combine features of a digital multimeter and insulation resistance tester. Aside from the typical multimeter functions, these meters can also measure insulation resistance, PI, DAR, and automatically calculate resistance ratio to determine the insulation status.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
10
People watching this product now!
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
-
-
Features
- Auto power off
- LCD backlight
- High voltage output alarm
- 99-group data storage
- Data hold
- Meets IEC 61557:Â 61557-1:2007;Â 61557-2:2007;Â 61557-4:2007
Details
Specifications Range UT505B Insulation resistance (Ω)  50V 50V/100V/250V/500V/1000V 0%~20% 0.01MΩ~50MΩ ±(3%+3) 50MΩ~1GΩ ±(3%+3) 100V 1GΩ~10GΩ ±(10%+3) 0.01MΩ~100MΩ ±(3%+3) 100MΩ~1GΩ ±(3%+3) 250V 1GΩ~20GΩ ±(10%+3) 0.01MΩ~200MΩ ±(1.5%+5) 200MΩ~1GΩ ±(1.5%+5) 500V 1GΩ~50GΩ ±(10%+3) 0.01MΩ~500MΩ ±(1.5%+5) 500MΩ~1GΩ ±(1.5%+5) 1000V 1GΩ~100GΩ ±(10%+3) 0.1MΩ~2000MΩ ±(1.5%+5) 2GΩ~9.9GΩ ±(5%+3) 10GΩ~20GΩ ±(7%+3) 20GΩ~200GΩ ±(20%+3) Load current 50V (R=50kΩ) 1mA 0%~10% 100V (R=100kΩ) 1mA 0%~10% 250V (R=250kΩ) 1mA 0%~10% 500V (R=500kΩ) 1mA 0%~10% 1000V (R=1MΩ) 1mA 0%~10% Short circuit current <2mA Leakage current (A) 10~2000μA ±(10%+3) Low resistance (Ω) 0.01Ω~20kΩ (about 5V/>200mA) 0.01Ω~100Ω (about 5V/>200mA/20mA optional) ±(1.5%+3) General resistance (Ω) 0.01kΩ~10MΩ ±(3%+3) DC voltage (V) 0V~600V ±(2%+3) AC voltage (V) 0V~600V ±(1.5%+5) Frequency (Hz) 45~1kHz ±(0.1%+3) Capacitance (F) 100pF~500μF ±(5%+5) Features Display count 6000 Auto range/True RMS √ Step voltage 10% steps at 50%~120% of range √ DAR 60s/15s and 60s/30s √ PI/Timing measurement √ Auto discharge √ Auto fuse check √ Analog bar graph √ Continuity buzzer √ Comparison measurement √ Low battery indication √ General Characteristics Power 1.5V battery (LR6) x 6 Display 78mm x 59mm Product color Red and grey Product net weight 630g Product size 103mm x 225mm x 59mm Standard accessories Batteries, test leads, test probes, alligator clips Standard individual packing Carrying bag, gift box, English manual Standard quantity per carton 20pcs Standard carton measurement 515mm x 380mm x 385mm (0.075 CBM per standard carton) Standard carton gross weight 20.8kg Optional accessory Remote test lead
-
| Manufacturer | UNI-T |
|---|---|
| Price Unit | Each |
| Weight | 1.300 KG |
| Is Featured | No |
